The continuing construction and upkeep of the transportation infrastructure needed to support our contemporary society depends heavily on tunnels. Our road and rail tunnels not only link towns, but they also serve as essential links that let people and goods to move more freely throughout our transportation networks, thereby facilitating continued population expansion. Significant engineering problems are frequently presented by tunneling, necessitating practical expertise, technical proficiency, and dedication to provide positive project outcomes.
A specialized area of civil engineering, tunnel engineering is largely a combination of geotechnical and structural engineering. A tunnel engineer is very knowledgeable about various types of ground (soil and rock), the behavior of the ground, and how the earth interacts with the construction that is built inside. An underground station or a road tunnel, for example, which typically have a design life of 100 years, are examples of structures that a tunnel engineer designs engineering solutions to safely excavate and support the ground and the structure to be built inside the tunnel.
Building tunnels is the focus of the civil engineering specialty known as tunnel engineering. There is a lot more to learn about this fascinating industry. Of course, no microscopic virus can justify keeping us from travelling for necessary reasons. Consequently, you will always have professional opportunities available to you.
What are the Tunnels?
A tunnel is a passageway that has been dug through the ground, rock, or dirt and is entirely enclosed, with the exception of the entrance and exit locations, which are often at either end. A pipeline is not a tunnel, even if some modern tunnels have been built using immersed tube construction methods rather than the more traditional tunnel boring techniques.
A tunnel may be utilized for canal flow, rail transportation, or both pedestrian and automobile traffic. The main hubs of a rapid transport system are typically found in tunnels. Aqueducts that convey water for human consumption or hydroelectric power plants are examples of certain tunnels. Sewers are examples of other tunnels. Utility tunnels are used to connect buildings so that people and equipment may move about more freely. They also deliver steam, chilled water, electrical power, and communications cables.
Civilian tunnels are constructed for the purpose of transporting persons, contraband, and weapons, as opposed to military tunnels. For instance, wildlife crossing tunnels are built to let wildlife safely traverse barriers established by people.
What is meant by Tunnel engineering?
With knowledge and skills from civil engineering, geological engineering, mining engineering, mechanical engineering, electrical engineering, geophysics, geology, and other disciplines, tunnel engineering is a truly interdisciplinary field.
The following are the course’s primary modules:
- General Tunneling Aspects
- Engineering Geology (stresses, strains, and anisotropy)
- Engineering Rock Mechanics
- Soil Mechanics & Geotechnical Engineering, Investigations
- Using Rock and Soil Mechanics
- Analytical and Numerical Methods for Diagnosis Phase; Therapy Phase for Preliminary Confinement
- Type A tunnels: Analytical
- Methods of Analysis and Design
- Type A Tunnels: Excavation in Rock
- Therapy Phase and Construction Phase for Pre-confinement (Type B & C Tunnels) and Final Lining
- Mechanized Tunneling with Face Control for Type B and C Tunnels
- Monitoring and Surveying
- Risk Assessment & Management
Methods of Tunneling
Various techniques can be employed for the planning and building of tunnels, based on the size of the tunnel needed, the specific ground and groundwater conditions, the depth, the amount of space available, and other factors.
- Drill and blast
Prior to the invention of tunnel boring machines, this was often utilized for hard rock where digging was impossible (TBM). Although the procedure is slower than using TBM, it typically has fewer capital costs.
- Road headers
These powerful cutting booms-equipped track-mounted excavation machines are frequently employed in coal mining and civil engineering projects that call for a variety of tunnel sizes. They are fairly adaptable and can be equipped with additional machinery, such as gathering arms for spoil, dust-reduction water jets, and conveyors for debris removal.
- Open-cut method
This method, often known as “cut-and-cover,” works well for short tunnels. It entails creating an open trench within of which the tunnel is built. After that, the trench is backfilled. The building of the side walls may happen before or after digging the trench, depending on the state of the earth.
- Cut and cover
In a shallow trench, the “roof” slab of the tunnel is first constructed using the cut and cover technique. The tunnel can then be built underneath the “cover” and the trench can be backfilled. The benefit of is that it frees up the area above the tunnel for other purposes.
- Immersed-tube method
For tunnels that span deep water, this approach is appropriate. Prefabricated concrete or steel tunnel segments are lowered into a constructed trench at the level of the sea or a riverbank. The trench is subsequently backfilled, and any further safety measures are built above.
A driving pit is built using the trenchless process known as pipe-jacking, and pieces of steel or concrete tube are then hydraulically jacked forward from the pit to create the tunnel lining. When placing services beneath roadways, railroad embankments, and canals, it is necessary to cause the least amount of disruption possible. Since the Northern Pacific Railroad Company used pipe jacking for the first time in the United States in 1892, it has been widely adapted. Due to its simplicity and the fact that it prevents ground settlement, it is frequently chosen.
Similar to pipe-jacking, however instead of a pipe, a box-shaped segment is jacked forward, which may allow for the creation of a larger tunnel.
This is mostly used for installing conduit and has a spinning cutting head that cannot be directed. As it inserts a tube or sleeve into the ground, a rail-mounted machine augers the surrounding dirt. The excavated material is moved back down the sleeve and into the shaft by the auger as it rotates, cutting the borehole’s face. The machine inserts a length of sleeve, which it then retracts so that another length of sleeve can be added and the auger flight prolonged. Then, this procedure is repeated. There are now also guided auger boring technologies available.
- Micro tunneling
Micro tunneling machines, which can operate in nearly any type of ground condition, are generally used to bore tunnels that are too small for workers to access, such as pipelines. With the use of laser technology, micro tunneling machines can be operated from the ground up, and spoil is removed from the cutting face by an auger inserted into the pipeline as it is being built. This is frequently utilized in situations when there must be little surface disturbance, like when building urban drainage systems.
According to Kramer, “any procedures that install pipes with a diameter of less than 36 inches (900mm) to a specified line and level by remotely directing the cutting head” are considered micro tunneling. In 1992, Kramer et al.
- Mined tunnel
This can be employed in areas with underlying materials that are capable of supporting themselves, like rock or strong clay. To develop the excavation, drill and blast methods or excavation with sprayed concrete liner are used.
- Whole face or ‘full-face’ boring / tunnel boring machines
Specifically made tunnel boring machines (TBM) are employed in this method to excavate the entire needed cross-section. Although it requires fewer workers and can be very time efficient, such a machine has substantial costs associated with its purchase and maintenance. Whole face borers can cut through hard rock, with the debris being collected by a conveyor, but they can be rigid when it comes to changing direction or cross-section. They grab the side of the tunnel to transmit thrust ahead.
Advantages of tunneling
When compared to other approaches, the tunneling method has the following advantages that are listed below:
- The tunneling methodology is more cost-effective than the open cut trench method when the depth surpasses a particular threshold.
- Surface life and ground-based activities like transportation are not hampered by tunnel construction.
- The strategy offers high-speed construction while using little power.
- Noise Pollution Drops
- These approaches don’t pose any threats from icebergs or snow in high-altitude environments.
- Surface and air interference are prohibited in tunnels.
- Having tunnels with gradual inclines helps to cut down on hauling expenses.
- Compared to bridges, tunneling offers a major benefit for public utility transit.
- The tunneling strategy is utilized to solve the issue when a risky open cut to a nearby structure is necessary.
- The tunneling offers greater protection in circumstances involving aerial combat and bombing.
Disadvantages of tunneling
The tunneling approach has some drawbacks as a result of its intricacy and difficulty. Among them are:
- There are several disadvantages to the tunneling strategy because of its complexity and difficulty.
- The start-up cost for the tunnel is substantial as compared to the open cut approach.
- To successfully execute this technique, a group of extremely skilled and knowledgeable designers and engineers is required.
- From the start of the tunneling project until the very end, there must be stricter and ongoing supervision.
- To conduct tunneling operations, very specialized and advanced equipment is required.
What does a Tunneling Engineer do?
Highly skilled civil engineers known as tunnel engineers are in charge of planning and overseeing projects involving tunneling. They are involved at every stage of the tunnel construction process, from the first design phases through the day the first car or train passes through.
There are numerous methods for creating tunnels, each requiring specialized knowledge and tools. Tunnels constructed using explosives, sprayed concrete coated tunnels, tunnels bored using tunnel boring machines (TBMs), and tunnels constructed using pipejacking, pipe ramming, or thrust boring are a few examples of these techniques.
You need have in-depth understanding of construction methods, substantial expertise with civil engineering and tunnel design, and exceptional project management abilities to succeed as a tunnel engineer. A top-notch tunnel engineer can accurately assess the engineering requirements needed to execute the project and picture the entire tunnel construction. The following are the tunnel engineer’s primary duties:
- A meeting to discuss the project’s scope and scale with the engineering team.
- Producing rough design concepts and outlining potential engineering tasks.
- Complete the tunnel design and oversee all engineering projects.
- Helping to draught IDRIS Preliminary Design Reports.
- Acquiring the project’s requisite permissions and approvals.
- Creating the project’s bid documentation.
- Aiding in the screening of prospective contractors.
- supplying engineering drawings and paperwork to contractors.
- Carrying out on-site progress and safety assessments.
- Offering program assistance and resolving construction-related problems.
Skills required to become Tunneling Engineer
To become a tunneling engineer, you must possess the following technical skills:
- Execution of the work schedule. Construct a method statement.
- In charge of daily TBM inspection and operation for tunneling projects
- Locate and fix technical and tunneling issues
- Coordinate with the TBM operator to manage tunneling KPI and parameters
- Manage tunnel team to complete target rings safely at the end of each shift and transfer to the following shift.
- Controlling construction activity and worker management
- Ascertain that tunneling operations are conducted safely and in compliance with the method description.
- Construction and building knowledge
- Outstanding mathematics, IT, and critical-thinking abilities
- Communication and teamwork abilities
- Excellent focus on detail.
You might also interested in
- 5 Ways An Internship In Germany Can Benefit You
- Geotechnical Engineer Job Description and Salary Details
- Best heavy equipment to use for construction
- Top Books on Advanced Geotechnical Engineering
- Books on Geotechnical Engineering For Students and Engineers
Essential qualifications required to make career in Tunneling
When planning and designing a tunneling project, a section engineer is engaged. This can entail creating tunnel constructions and acquiring the building supplies.
- A bachelor’s degree in geotechnical engineering, civil engineering, or a related discipline
- Demonstrated experience working as a tunnel engineer.
- Expertise building tunnels through both hard and soft rock.
- Comprehensive understanding of TBM and NATM excavation methods.
- Technical expertise in trenchless building.
- In-depth understanding of structural engineering and geology.
- Strong project management abilities.
- Expertise in CAD and AutoCAD design programs.
- A keen eye for detail and superior problem-solving abilities.
Salary details for Tunneling Engineer
Tunnel Engineer salary in India ranges between ₹ 3.3 Lakhs to ₹ 20.1 Lakhs with an average annual salary of ₹ 6.6 Lakhs. The salaries of Tunnel Engineers in the US range from $120,000 to $155,000, with a median salary of $147,000.
A specialized area of civil engineering, tunnel engineering is largely a combination of geotechnical and structural engineering. A tunnel engineer is very knowledgeable about various types of ground (soil and rock), the behavior of the ground, and how the earth interacts with the construction that is built inside which makes them most curious professional. If you have the necessary skill sets, you can prove that tunnel engineering is the ideal career path for you.
Typically, universities do not offer courses in tunnel engineering. Instead, the specific skill set is acquired through work experience under the guidance of a capable mentor. Being able to watch the process of constructing the underground area is one of the wonderful things about being a tunnel engineer. No matter how much experience you have, the scope of these megaprojects is nearly incomprehensible.
